1" Handlebar — 1" clamping, 31" width, 4-1/4" rise

BILTWELL 1" Handlebar — 1" clamping, 31" width, 4-1/4" rise

BILTWELL
0601-5134
6014-1056
Seamless 4130 chromoly with CNC mandrel bends and TIG-welded joints. For aftermarket/custom use; not notched for TBW.
Hurry! only 7 items left in stock.
€206.97
€270.65
Save €63.68
VAT included
local_shipping In stock, ships in 2-3 days

Add to Compare
Add to Wishlist

The 1" handlebar is built from seamless 4130 chromoly tubing with a 1" outside diameter and a .120" (3 mm) wall for a dependable strength-to-weight balance. 🔧

All bends are formed on a CNC bender using internal mandrels to minimize flat spots and maintain consistent tube shape.

Precision-mitered joints are TIG-welded for clean, strong seams ideal for aftermarket and custom applications.

Please note: this handlebar is not notched for throttle-by-wire (TBW) applications.

: 0601-5134
In Stock

Data sheet

Units
Each
Color/Finish
Chrome
Base Color
Silver
Brand
BILTWELL
Width
78,5 cm (31")
Height
21.5 cm (8-1/2")
Type/Bend
Keystones
Handlebar Diameter
25,4 mm (1")
Center Width
19 cm (7-1/2")
Clamping Diameter
25,4 mm (1")
Controls Diameter
25.4 mm (1")
End Rise
11 cm (4-1/4")
Pullback/Sweep
57,2 mm (2-1/4")
Rise
11 cm (4-1/4")
Material
Chromoly
Finish
Chrome
