Exhaust Stud Drill Plate — Exhaust, Blue anodized

JIMS Exhaust Stud Drill Plate — Exhaust, Blue anodized – 94-02, 04-17 Dyna, 84-85, 87, 94-98, 01, 10, 16 Touring, 11-16 Trike, 90-00, 04-07, 09-17 Softail, 00-02 CVO, 84-86 Big Twin, 84-90 FXR, 86-92, 04, 09-12, 14, 18-20 Sportster

JIMS
DS-197032
1705
Precision drill plate that aligns seals for even installation; compatible with flange nuts. Made in the U.S.A.
Hurry! only 5 items left in stock.
€194.87
€236.63
Save €41.76
VAT included
local_shipping In stock, ships in 2-3 days

Add to Compare
Add to Wishlist

This tool positions the seal evenly into the cylinder head port, ensuring a flush fit and dependable sealing. 🔧

It works with flange nuts to maintain alignment during installation, reducing the chance of damage to the seal.

Made in the U.S.A. 🇺🇸

: DS-197032
In Stock

Data sheet

Units
Each
Color/Finish
Blue, Anodized
Style
Drill Plate
Brand
JIMS
Application
Exhaust
Harley Family
CVO
Dyna
FXR
Softail
Sportster
Touring
Trike
Vintage Big Twin
